Replacement fuel water separator 504086268 separate water

Short Description:

Send email to us

Product Detail

Product Tags

Size

Height : 161.3mm

Shell Diameter : 108.6mm

Filter Implementation Type : Screw-on Filter

Recommended part numbers for special tools : -

Connector Thread : 1″-14

Starting Torque : 20Nm

OEM

HYUNDAI : 3194552161

IVECO : 2997374

IVECO : 2997376

IVECO : 42549295

IVECO : 504086268

IVECO : 504272431

LIEBHERR : 11081663

MERCEDES-BENZ : 0004771602

MERCEDES-BENZ : A0004771602

RENAULT TRUCKS : 7420745605

VOLVO : 20745605

VOLVO : 21088099

VOLVO : 21088101

Cross reference

BALDWIN : BF1292-O

BOSCH : F 026 402 132

DELPHI : HDF304

DONALDSON : P550747

DT : 7.24041

DT Spare Parts : 7.24041

FLEETGUARD : FS19920

FLEETGUARD : FS19950

HENGST FILTER : H7091WK10

MAHLE ORIGINAL : KC 374D

MANN-FILTER : WK1070X

MANN-FILTER : WK 1070 x

PARKER RACOR : R90T-D-MAX

RACOR : R90DMER02

RACOR : R90MER02

RACOR : R90T-DMAX

Don’t Forget to Change the Fuel Filter

Because the symptoms of fuel filter blockage, fuel injection nozzle carbon deposition, fuel pump blockage and other oil circuit blockage are similar, if other oil circuit failure problems are ruled out, you should consider whether the fuel filter should be replaced when the following 4 symptoms appear. .

First, the early blockage accelerates the car

The impurities in the fuel are filtered through the filter paper layer by layer to supply fuel to the engine. If it is slightly blocked, it will cause the occasional mixed gas concentration to be too thin, and there will be a slight sense of frustration when accelerating. Early stage of filter clogging.

2. Slightly blocked the car begins to accelerate poorly, and the engine power decreases

This situation is more obvious when the fuel filter is slightly blocked, especially when the car is under heavy load, the power drop is very obvious, because when the filter is slightly blocked, there will be insufficient fuel supply. The wrong air-fuel ratio directly slows down the power of the car.

3. Serious blockage will cause unstable idle speed and jitter of the car

This is when the blockage is more serious, and there will be continuous insufficient combustion of the mixture, and the engine will be unstable at idling and more serious shaking.

4. Seriously blocked or unable to start the car or difficult to start

The occurrence of this phenomenon means that the blockage of the fuel filter is very serious. At this time, the car is not only accompanied by serious acceleration problems, but also difficult to start and difficult to drive.

The blockage of the fuel filter will cause the oil circuit to be blocked, the mixture ratio will be out of balance, and the mixture will not be fully burned, which will directly cause the engine to generate a large amount of carbon deposits. In order to ensure the good performance of the engine, the fuel filter generally needs to be replaced regularly and preventively. Generally, depending on the refueling product, the car needs to be replaced after driving 30,000 to 50,000 kilometers. If the refueling product is poor, the replacement cycle needs to be advanced. In fact, compared with the fuel filter, when the fuel oil is poor, the blockage of the fuel pump filter will be the first to bear the brunt.
