Factory supply filter 20998807 engine oil filter 20998807

Short Description:

Send email to us

Product Detail

Product Tags

Size

Outer diameter 1 : 113mm

Outer Diameter : 113mm

Inner diameter 1 : 56mm

Height : 202mm

Inner diameter : 46mm

Supplement/Supplementary Information : with seal

OEM

DEUTZ-FAHR : 490 3559

RENAULT TRUCKS : 74 20 796 782

RENAULT TRUCKS : 74 20 998 809

VOLVO : 20796785

VOLVO : 20998807

VOLVO : 21040164

Cross reference

BOSCH : F 026 407 252

DONALDSON : P550905

DT : 2.11130

DT : 6.24203

FEBI BILSTEIN : 35348

FIL FILTER : MLE 1511

FILTRON : OE 686

FLEETGUARD : LF16351

FRAD : 20.37.59/10

GIF FILTER : LI 374

GUD FILTERS : M 93

HENGST FILTER : E416H D86

KNECHT : OX 426D

KOLBENSCHMIDT : 4321-OX

KOLBENSCHMIDT : 50014321

LAUTRETTE : ELH 4772

MAHLE : OX 1026

MAHLE : OX 1026D

MAHLE : OX 426D

MAHLE FILTER : OX 1026

MAHLE FILTER : OX 426

MAHLE FILTER : OX 426 D

MAHLE FILTER : OX 426 D ECO

MANN-FILTER : HU 1390 x

Oil filter

The oil filter, also known as the oil filter, is located in the engine lubrication system. The upstream of the filter is the oil pump, and the downstream is the parts in the engine that need to be lubricated. The oil filter filters out harmful impurities in the oil from the oil pan, and supplies the crankshaft, connecting rod, camshaft, supercharger, piston ring and other moving pairs with clean oil, which plays the role of lubrication, cooling and cleaning, thereby prolonging the life of these parts.

Function of the oil filter

The function of the oil filter is to filter out the harmful impurities in the oil from the oil pan, and supply the crankshaft, connecting rod, camshaft, supercharger, piston ring and other moving pairs with clean oil, which plays the role of lubrication, cooling and cleaning. , thereby extending the life of these components.

Oil filter structure

According to the structure, the oil filter can be divided into replaceable type, spin-on type and centrifugal type; according to the arrangement in the system, it can be divided into full-flow type and split-flow type. The filter materials used in machine filtration include filter paper, felt, metal mesh, non-woven fabric, etc.
